Ubicom SX 48/52 Embedded Controller Devices

Memory Program 4K words
Data 262 bytes RAM
Interrupts Internal Clock or Counter 3
Response time 60ns (45 on the 75 Mips part)
External Port Pins 8
Response time 100ns (75 on the 75 Mips part)
IO Pins SX 48 36
SX 52 40
Power 30mA Sink/Source
Analog Comparators 1
Counters 1 (8 bit) plus 2 (16 bit)
Operating Voltage 3.0-5.5V (at 50Mhz)
Brown out detect 2.2/2.6/4.2V

Availability

$8.50 SX-52AC-50Mhz In stock Future datecodes of this device will run at 75MHz for the same price.
As of 2005/02/05 the 100MHz version of the SX 48/52 has been discontinued. All SX chips will now run at 75Mhz

See:

See also:

Code:

Questions:
