| Memory | Program | 64K-byte flash memory 16K-byte instruction SRAM |
|
| Data | 4K-byte SRAM | ||
| Interrupts | Internal | Clock or Counter | 2 |
| Response time | 3 cycles | ||
| External | Port Pins | 8 port B | |
| Response time | ? | ||
| IO | Pins | 52 | |
| Analog-to-Digital converters | 10-bit, 8-channel, 48 kHz | ||
| Analog Comparators | 1 Differential comparator with hysteresis | ||
| Serial to Parallel conversion | Two pairs of serializer/deserializers for 10BaseT (MAC/PHY), USB, etc... |
||
| Counters | 1 (8 bit RTC) 2 (16 bit PWM/Capture/Compare and prescalars) |
||
| Operating Voltage | 2.5-5.5V (at 50Mhz) | ||
| Brown out detect | 2.2/2.6/4.2V | ||
| Speed | 100MIPS (from a 4Mhz clock via PLL) Speed instruction for on-the-fly execution speed changes. Sleep with independant RTC wakeup |
||
| Package | 80-pin 14mm x 20mm x 2.8mm, 0.8 pitch, JDEC MO-112, CB-2 | ||
Single-cycle instruction execution on most instructions. 8x8 signed/unsigned single-cycle Multiply. 3-cycle internal interrupt response, including context save
Among the software modules that will be available for programming the IP2000 Internet Processors are 10base-T Ethernet, USB, UART, I2C, SPI, and Parallel Slave physical interfaces, and a complete TCP/IP stack.
Sample quantities of the IP2022 Internet Processor will be available in the first quarter of 2001. Offered in an 80-pin plastic quad flatpack (PQFP) package, pricing in quantities of 10,000 will be $13.30. The IP2022 will be the most cost-effective complete Internet connectivity solution available.
On-chip in-system debug (ISD) support. High-quality development tool chain support from multiple 3rd party vendors: Cygnus/Red Hat tool chain and Nohau's high-end debugger. Tools for developing with and using the IP2022 Internet Processor are available from leading suppliers. For example, the complete GNU tool suite, including C compiler, assembler, linker, utilities and GNU debugger, now supports the Ubicom IP2022. Announcements by other major tool vendors will follow shortly.
An IP2022 development board is available from Ubicom
See:
Comments:
See also:
Questions:
Our E80-0055 matches your application very well. This E80-0055 is (P)QFP-80 to PGA-80 Programming and Testing IC Adapter. On the top, it is a QFP IC Socket which fits your IP2022 exactly. The bottom is PGA-80 pin (0.1" pin-pitch) so you can directly plug into PGA Socket (ex. Mill-max P/N# 510-93-084-10-031). The unit cost is $99.50. We currently have 2 units in stock. There is 6-week lead time for this item. If you like to order, you can simply click the following link from our web site:
E80-0055:
http://cart.bcentral.com/ShoppingCart/AddToCart.asp?MID=4814314&PID=E80-0055&CHID=101
If you need any additional questions, please feel free to let us know.
Thanks.
Adapter Team
