Possible use as a web based teaching example.
let src = cv.imread('canvasInput'); let dst = new cv.Mat(); let dsize = new cv.Size(src.rows, src.cols); let x_cut_left = Math.round(src.cols*0.01) //distance in from the left where the near road starts let x_cut_right = 0//Math.round(src.cols*0.01) //what to cut off the right let road_center = 0.74 //percentage of center position of the road let x_center = Math.round((src.cols - x_cut_left - x_cut_right)*road_center) let x_road_far = Math.round(src.cols * 0.2) //width of the road in the distance let y_road_far = Math.round(src.rows*.45) //cut off the skyline let y_road_near = Math.round(src.rows *0.65) //cut off the car hood and dash let srcTri = cv.matFromArray(4, 1, cv.CV_32FC2, [ //upperleft, upperright, lowerleft, lowerright x_cut_left+x_center-x_road_far, y_road_far, x_center+x_road_far-x_cut_right, y_road_far, x_cut_left, y_road_near, src.cols-x_cut_right, y_road_near ]); let dstTri = cv.matFromArray(4, 1, cv.CV_32FC2, [0, 0, src.cols, 0, 0, src.rows, src.cols, src.rows]); let M = cv.getPerspectiveTransform(srcTri, dstTri); // You can try more different parameters cv.warpPerspective(src, dst, M, dsize, cv.INTER_LINEAR, cv.BORDER_CONSTANT, new cv.Scalar()); cv.imshow('canvasOutput', dst); src.delete(); dst.delete(); M.delete(); srcTri.delete(); dstTri.delete();
